EtherCAT I/O Solutions-Taiwan Pulse Motion

Showing 25–48 of 247 results

  • 107-D104-XNT Motionnet,Digital Slave(DIO)

    107-D104-XNT(32-CH.DO)

    ● 32-Ch. Motionnet® Digital I/O slave modules
    ● Max. 20Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Pluggable terminal block with spring plug connectors
    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-D122-NNT Motionnet,Digital Slave(DIO)

    107-D122-NNT(16-CH.DI/DO)

    16-Ch. Digital input / 16-Ch. Digital output
    ● Max. 20Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Pluggable terminal block with spring plug connectors
    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-D140-NXT Motionnet

    107-D140-NXT(32-CH.DI)

    Features

    ● 32-Ch. Motionnet® Digital I/O slave modules
    ● Max. 20Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Pluggable terminal block with spring plug connectors
    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-D140-NXT Motionnet

    107-D1xx Series(32)(32-CH)

        32-Ch. Digital input

        16-Ch. Digital input / 16-Ch. Digital output

        32 Ch. Digital output

    • SCB-1BB-06A / 10A / 20A / 30A / 50A / A0A

  • 107-D402H-XN Motionnet

    107-D402H-XN(16-CH.DO)

    Features

    ● 16-Ch. Motionnet® High current Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-D411H-NN Motionnet

    107-D411H-NN(8-CH.DI/DO)

    Features

    ● 16-Ch. Motionnet® High current Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-D533-NN Motionnet

    107-D533-NN(48-CH.DI/DO)

    Features

    ● 96-Ch. Motionnet® Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-125 x H-77 mm)

  • 107-D542-NN Motionnet

    107-D542-NN(64-CH.DI/32-CH.DO)

    Features

    ● 96-Ch. Motionnet® Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-125 x H-77 mm)

  • 107-D560-NX Motionnet,Digital Slave(DIO)

    107-D560-NX(96-CH.DI)

    Features

    ● 96-Ch. Motionnet® Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-125 x H-77 mm)

  • 107-D533-NN Motionnet
    107-D542-NN Motionnet

    107-D5xx Series(96-CH)

    Features

    ● 96-Ch. Motionnet® Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-125 x H-77 mm)

  • 107-D604-XN Motionnet

    107-D604-XN(32-CH.DO)

    Features

    ● 32-Ch. Motionnet® Short Circuit Protection Digital I/O slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Pluggable terminal block with spring plug connectors

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 2-Axis Controller Combo Motionnet

    107-M2A2-GEN(2 axis)

    Features

    ● 2-axis Motion Controller

    ● Max. 20Mbps transfer rate

    ● Ultra compact, a 2-axis integrated controller​​

    ● Max. 6.5MHz pulse output rate

    ● 28-bit counter for incremental encoder

    ● Programmable acceleration and deceleration time

    ● T-curve and S-curve velocity profiles support

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 107-T121-GEN(2 axis) Accessories,Terminal board

    107-T121-GEN(2 axis)

    Terminal board for 2-axis

    ● Dimensions:
    L-77 x W-123 x H-47mm

  • 107-T141-GEN(4 axis) Accessories,Terminal board

    107-T141-GEN(4 axis)

    Terminal board for 4-axis

    ● Dimensions:
    L-122 x W-157 x H-45mm

  • 107-T142-GEN(4 axis) Accessories,Terminal board

    107-T142-GEN(4 axis)

    Terminal board for 4-axis

    ● Dimensions:
    L-122 x W-104 x H-52mm

  • 107-T160-DUM(IO) Accessories,Terminal board

    107-T160-DUM(IO)

    Terminal board for IO Card

    ● Dimensions:
    L-122 x W-66 x H-52mm

  • 107-T160-DUMP(IO) Accessories,Terminal board

    107-T160-DUMP(IO)

    Terminal board for IO Card

    ● Dimensions:
    L-122 x W-66 x H-52mm

  • 107-T162-DUMG(4 axis) Accessories,Terminal board

    107-T162-DUMG(4 axis)

    Terminal board for 4-axis

    ● Dimensions:
    L-122 x W-84 x H-52mm

  • 108-A204 Motionnet

    108-A204(4-CH.AO)

    Features

    ● 4-Ch. Analog Output Motionnet® slave modules
    ● Max. 20Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnosis
    ● Connectors with screw terminal block
    ● DIN rail mounting (L-77 x W-124 x H-34 mm)

  • 108-A322 Motionnet

    108-A322(8-CH.AI/4-CH.AO)

    Features

    ● 8-Ch. Analog Input and 4-Ch. Analog Output Motionnet® slave modules

    ● Max. 20Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● Connectors with screw terminal block

    ● DIN rail mounting (L-77 x W-124 x H-32 mm)

  • 108-C142T_Motionnet_Motion Slave_Pulse Slave Modules_tpm商品圖800x600

    108-C142T

    Features

    ● 4-Ch. Encoder Motionnet® slave modules

    ● 2-Ch. Position compare and trigger output

    ● Support 3 Trigger modes : Fixed-Interval, Table Array and Toggle Array

    ● Max. 20Mbps transfer rate

    ● DIN rail mounting (L-77 x W-124 x H-34 mm)

  • 108-C144 Motionnet

    108-C144(4-CH)

    Features

    ● 4-Ch. Encoder Motionnet® slave modules

    ● 4-Ch. Position compare and trigger output

    ● Support 2 Trigger modes : Fixed-Interval and Table Array

    ● Max. 20Mbps transfer rate

    ● DIN rail mounting (L-77 x W-124 x H-34 mm)

  • Motionnet_Motion Slave_Pulse Slave Modules_108-C144F_tpm商品圖800x600

    108-C144F

    Features

    ● 4-Ch. Encoder Motionnet® slave modules

    ● 4-Ch. Position compare and trigger output

    ● Support Trigger mode : Fixed-Interval

    ● Max. 20Mbps transfer rate

    ● DIN rail mounting (L-77 x W-124 x H-34 mm)

  • 108-G180 Motionnet

    108-G180

    ● Max. 20Mbps transfer rate

    ● DCON transfers to Motionnet®

    ● Easy installation with RJ45 phone jack and LED diagnosis

    ● DIN rail mounting (L-77 x W-124 x H-38 mm)
