Showing 49–67 of 67 results
-
EZM-D402-XN(16-CH)
Features
● 16-Ch. Digital output
● Max. 20Mbps transfer rate
● Flexible I/O interface deployment
● Customize PCB mounting (L-98 x W-25 x H-77 mm)
-
EZM-D411-NN(8-CH.DI/DO)
Features
● 8-Ch. Digital input / 8-Ch. Digital output
● Max. 20Mbps transfer rate
● Flexible I/O interface deployment
● Customize PCB mounting (L-98 x W-25 x H-77 mm)
-
EZM-D4xx Series(16-CH.DI/DO)
Features
● 16 Ch. DI/O Slave Module
● Max. 20Mbps transfer rate
● Flexible I/O interface deployment
● Customize PCB mounting (L-98 x W-25 x H-77 mm)
-
-
LPE-L122(2 Rings)
Features
● PCI Express x1 compliant
● Low profile form factor
● Max. 20Mbps transfer rate
● 2 Rings of Motionnet® Master
● Max. 128 Motionnet® slave modules supported
● Easy installation with RJ45 phone jack and LED diagnostic
● Hardware IC with unique ID
-
MPE-L111(1 Ring)
Features
● mini PCI Express
● PCI Express mini Card Electromechanical Rev. 1.2
● Max. 20Mbps transfer rate
● 1 Ring of Motionnet® Master
● Max. 64 Motionnet® slave modules supported
-
PCE-L122-DCO(2 Rings)
Features
● PCI Express x1 compliant
● Max. 20Mbps transfer rate
● 2 Rings of Motionnet Master
● Max. 128 Motionnet slave modules supported
● Easy installation with RJ45 phone jack and LED diagnostic
● Compare output FIFO x 2
● High Speed FIFO LATCH x 4
● General purpose isolated I/O: 4 DI and 4 DO
● Hardware IC with unique ID -
PCE-L123-DCO(3 Rings)
Features
● PCI Express x1 compliant
● Max. 20Mbps transfer rate
● 3 Rings of Motionnet Master
● Max. 192 Motionnet slave modules supported
● Easy installation with RJ45 phone jack and LED diagnostic
● Compare output FIFO x 2
● High Speed FIFO LATCH x 4
● General purpose isolated I/O: 4 DI and 4 DO
● Hardware IC with unique ID -
PCE-M114-GL(1 Ring)
● PCI Express x1 compliant
● On-board 4-axis motion control with Max. 6.5MHz pulse output rate
● 1 Rings of Motionnet® Master
● Max. 64 Motionnet® slave modules support
● Linear, circular, helical and continuous interpolation
● High speed position latch function
● Compare output FIFO x 2
● Manual pulse generator
● General purpose isolated I/O: 3 DI and 4 DO
-
PCE-M114-GM(2 Rings)
Features
● PCI Express x1 compliant
● On-board 4-axis motion control with Max. 6.5MHz pulse output rate
● 2 Rings of Motionnet® Master
● Max. 128 Motionnet® slave modules support
● Linear, circular, helical and continuous interpolation
● High speed position latch function
● Programmable acceleration and deceleration time
● Programmable pulse output and interrupt
● Position compare and trigger output
● Compare output FIFO x 2
● Manual pulse generator
● General purpose isolated I/O : 3 DI and 4 DO
● Hardware IC with unique ID
-
PCE-M118-GL(1 Ring)
● PCI Express x1 compliant
● On-board 8-axis motion control with Max. 6.5MHz pulse output rate
● 1 Ring of Motionnet®Master
● Max. 64 Motionnet® slave modules support
● Compare output FIFO x 4
-
STP-M111A(1 axis/2-phase)
Features
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
● Max. 20Mbps transfer rate
● 1-axis micro-step control
● M111A : Current 2.0A
● Bi-polar current driving system
● 1/32 Micro-Step
● Encoder feedback
● Dimension : L-68 x W-125 x H-29mm
-
STP-M112A(1 axis/2-phase)
Features
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
● Max. 20Mbps transfer rate
● 1-axis micro-step control
● M112A : Current 4.5A
● Bi-polar current driving system
● 1/256 Micro-Step
● Encoder feedback
● Dimension : L-74 x W-140 x H-29mm
-
STP-M510A
Feature
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
- Motionnet® 5-phase micro-step drive
- STP-M510A : Current 0.75A
- STP-M511A : Current 1.4A
- Constant-current Driving System
- Adjustable running current and stop current
- Support Multiple Resolution (1 ~ 125,000)
- Support 0.36° and 0.72°step angle
- Support Encoder feedback
- Low Vibration and Noise
- DIP switch for address setting
- Dimensions : L-75 x W-140 x H-30 mm
-
STP-M511A
Feature
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
- Motionnet® 5-phase micro-step drive
- STP-M510A : Current 0.75A
- STP-M511A : Current 1.4A
- Constant-current Driving System
- Adjustable running current and stop current
- Support Multiple Resolution (1 ~ 125,000)
- Support 0.36° and 0.72°step angle
- Support Encoder feedback
- Low Vibration and Noise
- DIP switch for address setting
- Dimensions : L-75 x W-140 x H-30 mm
-
STP-M512(1 axis/5-phase)
Features
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
● 5-phase Motionnet® micro-step drive
● Lowest vibration and noise
● High positional accuracy
● Adjustable running current and stop current
● Selectable micro step
● Max. 20Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Dimension : L-79 x W-140 x H-30mm
-
SVR-M111(1 axis/2-phase)
Features
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
● Max. 20Mbps transfer rate
● 1-axis closed-loop control
● M111 : Current 2.8A
● Bi-polar current driving system
● Resolution : 500~50,000 pulse / revolution
● Encoder feedback
● DIP switch for address setting
● Dimensions : L-74 x W-140 x H-31 mm
-
SVR-M112(1 axis/2-phase)
Features
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
● Max. 20Mbps transfer rate
● 1-axis closed-loop control
● M112 : Current 4.2A
● Bi-polar current driving system
● Resolution : 500~50,000 pulse / revolution
● Encoder feedback
● DIP switch for address setting
● Dimensions : L-74 x W-140 x H-31 mm
