Showing 49–72 of 250 results
108-H104(4-CH)
Features
● 4-Ch. Hub Motionnet® slave modules
● Max. 20Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnosis
● DIN rail mounting (L-77 x W-69 x H-32 mm)
108-P144(4-CH)
Features
● 4-Ch. up / down 32-bit Counter Motionnet® slave modules
● Max. 20Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnosis
● Programmable input filter
● DIN rail mounting (L-77 x W-124 x H-34 mm)
108-T140(8-CH)
Features
● 8-Ch. Analog Input Motionnet® slave modules
● Max. 20Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnosis
● Connectors with screw terminal block
● DIN rail mounting (L-77 x W-124 x H-32 mm)
2-Axis Controller Combo
$2.00Select options This product has multiple variants. The options may be chosen on the product page2-Axis Controller Combo
$1.00Select options This product has multiple variants. The options may be chosen on the product page207-A202F(4-CH.AO)
Features
● 4-Ch. AO slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A204F(8-CH.AO)
Features
● 8-Ch. AO slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A220F(8-CH.AI)
Features
● 8-Ch. AI slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A220F(8-CH.AI)
Features
● 8-Ch. AI slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A220FI(8-CH.AI)
Features
● 8-Ch. AI slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A320F 8AI
Features
● 8-Ch. AI module with pluggable terminal
● AI Wire-break detection
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A321FC (8CH AI & 2CH AO)
Features
● 8-Ch. AI and 2-Ch. AO slave module with pluggable terminal
● AI Wire-break detection
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-A321FCI Analog 8AI 2AO
Features
● 8-Ch. AI and 2-Ch. AO slave module with pluggable terminal
● AI Wire-break detection
● Max. 100Mbps transfer rate
● Rotary switch for address setting
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-ADIO-KIT
Features
● 8DI / 8DO / 8AI / 2AO ADIO module
● Max. 100Mbps transfer rate
● LED diagnostic
● DIP switch for address setting
● Customize PCB mounting (L-98 x W-26 x H-77 mm)
207-AIO-KIT
Features
- EtherCAT communication standard
- 8-Ch. AI and 2-Ch. AO slave module
- Integrate knobs and voltage meter for easy testing
- Include connectors for external components
- Suitable for both beginners and advanced users
- DIN rail mounting
207-C344F Position Comparison Trigger
Features
- 4-channel Encoder input: 4-ch EA and EB ( 2-ch include EZ)
- Encoder input frequency: Max. 6.5 MHz for 4xAB mode
- Encoder mode: 4xAB ; CW/CCW ; Pulse/DIR
- CMP Trigger out: Line drive output
- Trigger mode: Interval, Table and Toggle
- Auto Trigger Max. 5MHz
- Table Trigger, 4096pts allocatable for all channels
- Toggle Trigger, 4096pts allocatable for all channels
- Programmable Trigger Out Pulse Width
- 4-channel Latch function , Max. 10 KHz( 256 pt/ch)
- Rotary switch for address setting
- DIN rail mounting
207-D204-XNS(32-CH.DO)
Features
● 32-Ch. DO slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-D204-XPS(32-CH.DO)
Features
● 32-Ch. DO slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-D222-NNS(16-CH.DI/DO)
Remote IO Features
● 16-channel Digital input and 16-channel Digital output with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-D222-PPS(16-CH.DI/DO)
Features
● 16-channel Digital input and 16-channel Digital output
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-65 x H-104 mm)
207-D240-NX(32-CH.DI)
Features
● 32-Ch. DI slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-D240-PX(32-CH.DI)
Features
● 32-Ch. DI slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
207-D402H-XNS(16-CH.DO)
Features
● 16-Ch. DO slave module with pluggable terminal
● Max. 100Mbps transfer rate
● Easy installation with RJ45 phone jack and LED diagnostic
● Pluggable terminal block with spring plug connectors
● DIP switch for address setting
● DIN rail mounting (L-122 x W-66 x H-104 mm)
