Showing 73–96 of 245 results

  • 207-D411H-NNS EtherCAT Remote IO

    207-D411H-NNS(8-CH.DI/DO)

    Features

    ●8-ch DI and 8-ch DO  500mA Output Current

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 207-D411H-PPS EtherCAT Remote IO,Digital Slave,DIO

    207-D411H-PPS(8-CH.DI/DO)

    Features

    ● 16-Ch. DO slave module with pluggable terminal

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-66 x H-104 mm)

  • 207-D521-NNS EtherCAT Remote IO,Digital Slave,DIO

    207-D521-NNS(32-CH.DI/16-CH.DO)

    Features

    ● 32-Ch. DI and 16-Ch. DO with NPN type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors EtherCAT IO

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-127 x H-104 mm)

  • 207-D521-PPS EtherCAT Remote IO

    207-D521-PPS(32-CH.DI/16-CH.DO)

    Features

    ● 32-Ch. DI and 16-Ch. DO with PNP type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-127 x H-104 mm)

  • 207-D522-NNS EtherCAT Remote IO,Digital Slave,DIO

    207-D522-NNS(32-CH.DI/DO)

    Features

    ● 32-Ch. DI and 32-Ch. DO with NPN type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-103 x H-104 mm)

  • 207-D522-PPS EtherCAT Remote IO

    207-D522-PPS(32-CH.DI/DO)

    Features

    ● 32-Ch. DI and 32-Ch. DO with PNP type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-103 x H-104 mm)

  • 207-D532-NNS EtherCAT Remote IO,Digital Slave,DIO

    207-D532-NNS(48-CH.DI/32-CH.DO)

    Features

    ● 48-Ch. DI and 32-Ch. DO with NPN type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-116 x H-104 mm)

  • 207-D532-PPS EtherCAT Remote IO

    207-D532-PPS(48-CH.DI/32-CH.DO)

    Features

    ●  48-Ch. DI and 32-Ch. DO with PNP type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-116 x H-104 mm)

  • 207-D533-NNS EtherCAT Remote IO

    207-D533-NNS(48-CH.DI/DO)

    Features

    ● 48-Ch. DI and 48-Ch. DO with NPN type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-123 x H-104 mm)

  • 207-D533-PPS EtherCAT Remote IO,Digital Slave,DIO

    207-D533-PPS(48-CH.DI/DO)

    Features

    ●  48-Ch. DI and 48-Ch. DO with PNP type

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-123 x H-104 mm)

  • 207-D540-NX EtherCAT Remote IO

    207-D540-NX(Available Soon)(64-Ch.DI)

    Features

    ● 64-Ch. DI/O slave module with pluggable terminal

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-102 x H-104 mm)

  • 207-D540-PX EtherCAT Remote IO,Digital Slave,DIO

    207-D540-PX(Available Soon)(64-CH.DI)

    Features

    ● 64-Ch. DI/O slave module with pluggable terminal

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-102 x H-104 mm)

  • 207-D542-NNS EtherCAT Remote IO,Digital Slave,DIO

    207-D542-NNS(64-CH.DI/32-CH.DO)

    ● 64-Ch. DI and 32-Ch. DO with NPN type
    ● Max. 100Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Pluggable terminal block with spring plug connectors
    ● DIP switch for address setting
    ● DIN rail mounting (L-122 x W-123 x H-104 mm)

  • 207-D542-PPS EtherCAT Remote IO

    207-D542-PPS(64-CH.DI/32-CH.DO)

    ● 64-Ch. DI and 32-Ch. DO with PNP type
    ● Max. 100Mbps transfer rate
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Pluggable terminal block with spring plug connectors
    ● DIP switch for address setting
    ● DIN rail mounting (L-122 x W-123 x H-104 mm)

  • 207-D560-NX EtherCAT Remote IO

    207-D560-NX(Available Soon)(96-CH.DI)

    Features

    ● 96-Ch. DI/O slave module with pluggable terminal

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-123 x H-104 mm)

  • 207-D560-PX EtherCAT Remote IO,Digital Slave,DIO

    207-D560-PX(Available Soon)(96-CH.DI)

    Features

    ● 96-Ch. DI/O slave module with pluggable terminal

    ● Max. 100Mbps transfer rate

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Pluggable terminal block with spring plug connectors

    ● DIP switch for address setting

    ● DIN rail mounting (L-122 x W-122 x H-104 mm)

  • 207-M2A2-GEN EtherCAT IO motion control

    207-M2A2-GEN(2 axis)

    Features

    ● Max. 100Mbps transfer rate

    ● Ultra compact, a 2-axis integrated controller

    ● Max. 6.5MHz pulse output rate

    ● 32-bit counter for incremental encoder

    ● Programmable acceleration and deceleration time

    ● T-curve and S-curve velocity profiles support

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● DIN rail mounting (L-122 x W-65 x H-104 mm)

  • EtherCAT_Motion Slave_Motion Slave Modules_207-M3A2-GEN
    EtherCAT_Motion Slave_Motion Slave Modules_207-M3A2-GEN

    207-M3A2-GEN(2 axis)

    Features

    ● EtherCAT 2-axis pulse train output module

    ● Distributed Clock 0.5 / 1 / 2 / 4 ms

    ● CiA402 device profile support CSP, PP, Home

    ● Pulse output mode support OUT/DIR, CW/CCW and 4xA/B Phase

    ● Pulse output mode frequency Max. 6.5MHz

    ● Encoder input frequency Max. 6.5MHz

    ● 2-ch Trigger output frequency Max. 100KHz



  • 4-Axis Controller Combo Motionnet PCIe PC-Based

    4-Axis Controller Combo

  • 4-Axis-Motion Card Combo

    4-Axis-Motion Card Combo

  • 4-Axis-Motionnet Master Card Combo PCIe PC-Based
    Card_PCE-M114-GL.GM

    4-Axis-Motionnet Master Card Combo(Terminal Board/Daughter Boards)

    PCE-M114-GL more information

    ● PCI Express x1 compliant

    ● On-board 4-axis motion control with Max. 6.5MHz pulse output rate

    ● 1 Rings of Motionnet® Master

    ● Max. 64 Motionnet® slave modules support

    ● Linear, circular, helical and continuous interpolation

    ● High speed position latch function

    ● Compare output FIFO x 2

    ● Manual pulse generator

    ● General purpose isolated I/O: 3 DI and 4 DO

  • 8-Axis-Motion Card Combo

  • 8-Axis-Motion Card Combo(Terminal Board/Daughter Boards)

    PCE-M118-GL

    provides servo drive/motor dedicated digital I/O interfaces,

    for example,Motionnet ALM, INP, and ERC and also machine dedicated digital I/O interfaces,

    for example, ORG, PEL, and EMG. These dedicated I/O signals guarantee the functionality via hardware and therefore reduces the loading of software.
