Showing 145–168 of 241 results

  • EZM-D2xx Motionnet,EziModule

    EZM-D2xx Series(64/96-CH)

    Features

    ● 64 / 96 Ch. DI/O Slave Module

    ● Max. 20Mbps transfer rate

    ● Flexible I/O interface deployment

    ● Customize PCB mounting (L-98 x W-25 x H-49 mm)

  • EZM-D402-XN Motionnet

    EZM-D402-XN(16-CH)

    Features

    16-Ch. Digital output

    ● Max. 20Mbps transfer rate

    ● Flexible I/O interface deployment

    ● Customize PCB mounting (L-98 x W-25 x H-77 mm)

  • EZM-D411-NN Motionnet

    EZM-D411-NN(8-CH.DI/DO)

    Features

    8-Ch. Digital input / 8-Ch. Digital output

    ● Max. 20Mbps transfer rate

    ● Flexible I/O interface deployment

    ● Customize PCB mounting (L-98 x W-25 x H-77 mm)

  • EZM-D411-NN Motionnet

    EZM-D4xx Series(16-CH.DI/DO)

    Features

    ● 16 Ch. DI/O Slave Module

    ● Max. 20Mbps transfer rate

    ● Flexible I/O interface deployment

    ● Customize PCB mounting (L-98 x W-25 x H-77 mm)

  • EZM-D604-XN Motionnet

    EZM-D604-XN(Available Soon)(32-CH.DI/DO)

    EZM-D604-XN

    32 Ch. Digital output

  • HAT-L132D

  • LPE-C122 PCIe Card,DAQ Card

    LPE-C122

    Features

    ● PCI Express x1 compliant

    ● Low profile form factor

    ● CAN 2.0 A,B Protocol

    ● Two independent CAN communication operation

    ● Up to 1 Mbit/s programmable transfer rate on each port

    ● 120 ohm termination resistor selected by jumper

  • LPE-L122 EtherCAT IO Motionnet PCIe PC-Based

    LPE-L122(2 Rings)

    Features

    ● PCI Express x1 compliant

    ● Low profile form factor

    ● Max. 20Mbps transfer rate

    ● 2 Rings of Motionnet® Master

    ● Max. 128 Motionnet® slave modules supported

    ● Easy installation with RJ45 phone jack and LED diagnostic

    ● Hardware IC with unique ID

  • MPE-L111 EtherCAT IO Motionnet PCIe PC-Based
    MPE-L111 EtherCAT IO Motionnet PCIe PC-Based

    MPE-L111(1 Ring)

    Features

    ● mini PCI Express

    ● PCI Express mini Card Electromechanical Rev. 1.2

    ● Max. 20Mbps transfer rate

    ● 1 Ring of Motionnet® Master

    ● Max. 64 Motionnet® slave modules supported

  • PCE-C122D PCIe Card,DAQ Card

    PCE-C122D

    Features

    ● PCI Express x1 compliant

    ● Low profile form factor

    ● CAN 2.0 A,B Protocol

    ● Two independent CAN communication operation

    ● Up to 1 Mbit/s programmable transfer rate on each port

    ● 120 ohm termination resistor selected by jumper

  • PCE-C122T_800x600

    PCE-C122T

    Features

    ● PCI Express x1 compliant

    ● CAN 2.0 A,B Protocol

    ● Two independent CAN communication operation

    ● Direct memory mapping to the CAN controllers

    ● Up to 1 Mbit/s programmable transfer rate on each port

    ● 120 ohm termination resistor selected by jumper

  • PCE-D104A-XN PCIe Card,DAQ Card

    PCE-D104A-XN(64-CH.DO)

    Features

    ● 64-Ch. Digital Output

    ● PCI Express x1 compliant

    ● Board ID

    ● Readable digital output signals​

  • PCE-D105A-XN PCIe Card,DAQ Card

    PCE-D105A-XN(80-CH.DO)

    Features

    ● 80-Ch. Digital Output

    ● PCI Express x1 compliant

    ● Board ID

    ● Readable digital output signals

  • PCE-D122IS-SN PCIe Card,DAQ Card

    PCE-D122IS-SN(32-CH.DI/DO)

    Features

    ● 32-Ch. Digital Input and 32-Ch. Digital Output

    ● PCI Express x1 compliant

    ● Board ID

    ● Readable digital output signals​

  • PCE-D132A-SN PCIe Card,DAQ Card

    PCE-D132A-SN(48-CH.DI/32-CH.DO)

    Features

    ● 48-Ch. Digital Input and 32-Ch. Digital Output

    ● PCI Express x1 compliant

    ● Board ID

    ● Readable digital output signals

  • PCE-D140A-SX PCIe Card,DAQ Card

    PCE-D140A-SX(64-CH.DI)

    Features

    ● 64-Ch. Digital Input

    ● PCI Express x1 compliant

    ● Board ID

    ● Readable digital output signals

  • PCE-D150A-SX PCIe Card,DAQ Card

    PCE-D150A-SX(80-CH.DI)

    Features

    ● 80-Ch. Digital Input

    ● PCI Express x1 compliant

    ● Board ID

  • PCE-L122-DCO EtherCAT IO Motionnet PCIe PC-Based

    PCE-L122-DCO(2 Rings)

    Features

    ●  PCI Express x1 compliant
    ● Max. 20Mbps transfer rate
    ● 2 Rings of Motionnet Master
    ● Max. 128 Motionnet slave modules supported
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Compare output FIFO x 2
    ● High Speed FIFO LATCH x 4
    ● General purpose isolated I/O: 4 DI and 4 DO
    ● Hardware IC with unique ID

  • PCE-L123-DCO EtherCAT IO Motionnet PCIe PC-Based

    PCE-L123-DCO(3 Rings)

    Features

    ● PCI Express x1 compliant
    ● Max. 20Mbps transfer rate
    ● 3 Rings of Motionnet Master
    ● Max. 192 Motionnet slave modules supported
    ● Easy installation with RJ45 phone jack and LED diagnostic
    ● Compare output FIFO x 2
    ● High Speed FIFO LATCH x 4
    ● General purpose isolated I/O: 4 DI and 4 DO
    ● Hardware IC with unique ID

  • PCE-M114-GL Motionnet PCIe PC-Based

    PCE-M114-GL(1 Ring)

    ● PCI Express x1 compliant

    ● On-board 4-axis motion control with Max. 6.5MHz pulse output rate

    ● 1 Rings of Motionnet® Master

    ● Max. 64 Motionnet® slave modules support

    ● Linear, circular, helical and continuous interpolation

    ● High speed position latch function

    ● Compare output FIFO x 2

    ● Manual pulse generator

    ● General purpose isolated I/O: 3 DI and 4 DO

  • PCE-M114-GM EtherCAT IO Motionnet PCIe PC-Based

    PCE-M114-GM(2 Rings)

    Features

    ● PCI Express x1 compliant

    ● On-board 4-axis motion control with Max. 6.5MHz pulse output rate

    ● 2 Rings of Motionnet® Master

    ● Max. 128 Motionnet® slave modules support

    ● Linear, circular, helical and continuous interpolation

    ● High speed position latch function

    ● Programmable acceleration and deceleration time

    ● Programmable pulse output and interrupt

    ● Position compare and trigger output

    ● Compare output FIFO x 2

    ● Manual pulse generator

    ● General purpose isolated I/O : 3 DI and 4 DO

    ● Hardware IC with unique ID

  • PCE-M114 (4 axis) PCIe Card,Motion Card

    PCE-M114(4 axis)

    Features

    ● On-board 4-axis motion control with Max. 6.5MHz pulse output rate

    ● Linear, circular, helical and continuous interpolation

    ● High speed position latch function

    ● Simultaneously start / stop on multiple axes

    ● Programmable acceleration and deceleration time

    ● Programmable pulse output and interrupt

    ● Position compare and trigger output

    ● High Speed FIFO LATCH x 2

    ● Compare output FIFO x 4

    ● Hardware IC with unique ID

  • PCE-M118-GL EtherCAT IO Motionnet PCIe PC-Based

    PCE-M118-GL(1 Ring)

    ● PCI Express x1 compliant

    ● On-board 8-axis motion control with Max. 6.5MHz pulse output rate

    ● 1 Ring of Motionnet®Master

    ● Max. 64 Motionnet® slave modules support

    ● Compare output FIFO x 4

  • PCE-M118(8 axis) PCIe Card,Motion Card

    PCE-M118(8 axis)

    Features

    ● PCI Express x1 compliant

    ● On-board 8-axis motion control with Max. 6.5MHz pulse output rate

    ● Linear, circular, helical and continuous interpolation

    ● High speed position latch function

    ● Simultaneously start / stop on multiple axes

    ● Programmable acceleration and deceleration time

    ● Programmable pulse output and interrupt

    ● Position compare and trigger output

    ● Compare output FIFO x 4

    ● Hardware IC with unique ID
